LTCC Bandpass Filter 14750-15050MHz for RF Microwave Applications

Product Overview

The BPLT14900-300-5 is a high-performance LTCC band pass filter designed for RF and microwave applications operating from 14750MHz to 15050MHz.With a center frequency of 14900MHz and compact surface mount package, this filter provides excellent frequency selectivity, low insertion loss and high out-of-band rejection.

It is suitable for satellite communication, wireless communication systems, RF modules, radar systems and other high-frequency applications.

Specifications

F0(MHz)：14900

Dimension (mm)：9.8*3.2*1.1

Features

• Small Volume & Compact Design: With ultra-compact dimensions of just 9.8 * 3.2 * 1.1 mm, it is highly suitable for space-constrained PCB layouts and miniaturized RF modules.
• High Rejection Performance: Delivers superior stopband attenuation of ≥40dB at 14100MHz and ≥40dB at 15900MHz, effectively minimizing signal interference.
• Short Delivery Time: As a direct manufacturer, we ensure optimized inventory and production schedules to meet your urgent project timelines.
• Custom Design Available: We specialize in standard and custom-design components, allowing us to tailor filter specifications to your exact system requirements.

Applications

• Satellite Communication Systems
• Radar Systems
• RF Front-End Modules
• Microwave Communication Equipment
• Wireless Base Stations
• Test and Measurement Equipment

FAQ

Q1: What is the frequency range of this LTCC band pass filter?
A: The BPLT14900-300-5 LTCC band pass filter operates from 14750MHz to 15050MHz, with a center frequency of 14900MHz and a bandwidth of 300MHz. It is designed for high-frequency RF and microwave applications requiring precise signal filtering.

Q2: Can this 14.9GHz LTCC band pass filter be customized for different frequency requirements?
A: Yes. We provide customized LTCC band pass filter solutions based on customer requirements, including center frequency, bandwidth, insertion loss, package size, and electrical performance specifications. Our engineering team can support prototype development and volume production for different RF applications.

Q3: What applications can use the BPLT14900-300-5 RF band pass filter?
A: The BPLT14900-300-5 is suitable for various RF and microwave systems, including satellite communication, radar systems, wireless communication equipment, RF front-end modules, and microwave testing equipment. Its compact LTCC package and high rejection performance make it suitable for space-limited high-frequency designs.
